Mobile insulated distribution cabinets
Distribution cabinets

The stage distribution box is a device that provides power supply and  protection for various stage lighting equipment. It is used in different  types of performances like weddings, outdoor shows, stages, concerts,  DJs, etc. Connect or disconnect circuits by manual or automatic switches, and  provide power-off protection or alarms in the event of circuit overload,  short circuit, or leakage.
Specifications

Specifications 1. Power supply: three-phase five-wire AC380±10%, frequency 50Hz/60Hz±5%

Input current: 63A 5P industrial socket IP44

Display: It has three-phase A.B.C direct-reading indepen-dent LCD current and voltmeter display, which can monitor various data in real time without switching
Output: 12-channel power socket SW3FPX+2-channel 19-core

Body: Exquisite and durable PE sheet; waterproof cabinet,   The waterproof level of the whole machine is IP54; The open is equipped with a protective cover
Product size (mm): 430*380*460
