Product Features

• •Adopts wavelength division multiplexing technology to realize high-definition audio and video transmission via one multimode LC optical fiber;
• •Easy for pipe routing and installation with excellent anti-interference performance;
• •TMDS signal is transmitted through a single multimode optical fiber, delivering outstanding anti-interference capability;
• •Supports HDCP / DDC / CEC pass-through;
• •Supports hot-plugging.

•Performance Parameters

• •Supported Protocol: HDMI 2.0, backward compatible with HDMI 1.4
• •Supported Functions: HDCP / DDC / CEC pass-through
• •Supported Resolution: 4K60Hz / 4K30Hz / 1080P / 720P
• •Transmission Rate: 18Gbps (6Gbps per channel)
• •Transmission Distance: 0~300 meters; adopts 850nm 50/125μm OM4 LC-LC multimode optical fiber (single fiber)
• •Power Supply: 5V power supply via Micro USB interface (both Source and Display ends need power supply simultaneously)
